Print Head
|
Piezo Technology, Epson DX5 Print-head,
180 Nozzles*8lines
|
Maximum Print/Cut Width
|
1600 mm
|
Print Resolution
|
540 dpi, 720 dpi, 1440 dpi
|
Print Mode
|
540 x 720dpi
|
720 x 720dpi ,720 x 1080dpi
|
720 x 1440dpi , 1440 x 1440dpi
|
Print Resolution
|
(3pass)20㎡/ H
|
(4pass)18㎡/ H
|
(6pass)15㎡/ H
|
(8pass)10㎡/ H
|
Ink
|
Sort
|
Water Based Ink / Eco Solvent Ink
|
Water Based Ink: dye ink 、Sublimation ink
|
Capacity
|
440cc x 2/color , 1000cc/color
|
Media
|
Width
|
1620 mm
|
Sort
|
PP Sythentic Paper, Vinyl Sheet, Film, Coated Paper,
Acid Proof Paper, Banner, Canvas etc.
|
Media Cutting
|
Cutting in Y direction by cutter on the head
|
Media Heater
|
Pre/Print/Post heater
|
Media Take-up Device
|
Roll take-up device (Standard),inside/outside selectable
|
Interface
|
USB 2.0
|
Power
|
AC 100V—120V±10%, AC 220V—240V±10%, 50/60±1Hz
|
Operation Environments
|
20°C ~ 35°C , 35%RH ~ 65%RH
|
Dimensions ( WxDxH )
|
2,538 x 739 x 1,424 mm
|
Weight
|
160 kg
|
