CHARACTERISTICS：
● PERFECTPRINTING QUALITY
4 colors and 400DPI, equipped with the most stable control system.
● MACHINE IS STABLE AND RELIABLE
The professional mechanical design and the precision manufacturing up
to the international standards make machine a stable and reliable
operation.
|
Content
|
Specification
|
|
Model
|
33VB
|
|
Print Head
|
XAAR 128, 200/400DPI
|
|
Quantity
|
8-16（PCS）
|
|
Maximum Printing Width
|
3250mm
|
|
Speed
|
Draft Mode
|
40.85m²/hr
|
|
Standard Mode
|
32.11m²/hr
|
|
High Quality Mode
|
24.92 m²/hr
|
|
Ink
|
Type
|
Solvent based ink
|
|
Color
|
Cyan Magenta Yellow Black
|
|
Print Cartridge Mode
|
1000ml/Color Main Tank
|
|
Ink-supply Mode
|
300ml/min auto ink supply by pump, Auto/Manual ink
supply, low ink detector
|
|
Media
|
Width
|
Maximum 3300
|
|
Type
|
Flex, vinyl, window film, polyester
|
|
Roll media or sheet media
(bigger than A4 or 210mm)
|
|
Feeding & take-up
|
With feeding（Take-up is optional）
|
|
Cleaning
|
Auto positive pressure cleaning
|
|
Pre-heat & dry System
|
With pre-heating & post-heating, cool fan.
|
|
Clamp
|
Manual adjustment media width
|
|
Print Interface
|
USB2.0
|
|
Print Head Height
|
2-4mm gap adjustable
|
|
RIP
|
Infiniti RIP, Maintop etc.
|
|
Input Voltage
|
100~240V 50Hz/60Hz
|
|
Printer Size
|
L4412mm×W870mm×1250mm
|
